Bronze Globe Valve

This GMK bronze globe valve has female National Pipe Taper (NPT) threads on both sides, a rising stem, a bronze seat, and a threaded bonnet for controlling the flow of liquids via pipes and water plumbing systems. The valve body and seat are made of bronze, which is both strong and resistant to corrosion, meeting the standards set by the American Society for Testing and Materials (ASTM). Both ends include female NPT threads for attaching to male-threaded pipes, and the threaded bonnet guarantees a watertight seal. Class is a standard for tolerance, construction, size, and wall thickness and has nothing to do with the maximum operating pressure. This globe valve has a stem that extends upward, making it useful in a range of pipe and water plumbing applications.

  • Size:DN15-DN600
  • Pressure:Class 150LB,Class 300LB,Class600LB,Class 900LB,PN10-PN250
  • Material:ASME B148 C95800,ASTM B148 C95500,ASTM B148 C95400,ASTM B62,ASTM B61,ASTM B148 C83600, ASTMB150 C63200,DIN1705 RG10(CuSn10Zn2) ect
  • Connection:Flange
  • Operate:Hand Wheel,Gear Operated,Pneumatic Operated,Electric Operated

CE Certification

ISO Standards

Warranty Included


GMK bronze globe valve controls the flow of liquid via a pipe system by a twisting action between the stem and disc. A seated disc extends into the cavity in the center of the valve and functions as a stopper when the stem is twisted either loosely or solidly, respectively. There are two types of stems that globe valves may have: non-rising (where the stem remains at the same height whether the valve is open or closed) and rising (in which the stem rises to signal whether the flow is on or off).


  • Powerful power to close off
  • Good to excellent controllability
  • decreased stroke length (compared to a gate valve)
  • Connectors come in tee, wye, and angle configurations, each with its own set of benefits.
  • Seats may be easily resurfaced or machined.
  • It is possible to utilize the valve as a check valve by separating the disc from the stem.



  • Through way type
  • Y type Globe valve
  • Angle Type globe valve
  • OS&Y, Rising Stem


Size DN15-DN600
Pressure Class 150LB,Class 300LB,Class600LB,Class 900LB,PN10-PN250
Material ASME B148 C95800,ASTM B148 C95500,ASTM B148 C95400,ASTM B62,ASTM B61,ASTM B148 C83600, ASTMB150 C63200,DIN1705 RG10(CuSn10Zn2) ect
Connection Flange
Operate Hand Wheel,Gear Operated,Pneumatic Operated,Electric Operated
Supply Ability 10000 Piece/Pieces per Month
Port Wenzhou/shanghai
Payment Terms L/C,D/A,D/P,T/T
  • Design Standard: MSS-SP80/BS5154/BS1873 ASME B16.34,EN3356/EN13709,BS5156,API602/ISO15761/BS5352,JIS B2071,JIS B20081,JIS B2082
  • End Connection: Flanged ASME B16.5, EN1092-1 (Flat Face FF or Raised Face flange (RF) , RING TYPE JOINT FLANGE(RTJ)
  • Face To Face: ASME B16.10 , EN558-1
  • Test and Inspection: API 598,DIN 3230,EN 12266
