DIN Ball Valve

DIN Ball Valve

The GMK DIN ball valve is a device that adheres to stringent European rules and is both cost-effective and of high quality. Its structure enables the opening or shutting off of the fluid by means of the sphere while performing a 45-degree rotation with the sleeve, and the body is built completely of aisi 316 stainless steel, a material that provides it remarkable resilience in most industrial applications. It contains PTFE + 15% FV seats, which both enhance wear resistance and assure absolute tightness, therefore preventing leaks that might be hazardous to either operators or the environment.

Size:DN15-DN600

Pressure:PN16 PN25 PN40 PN64

Material:A105, WCB, CF8, CF8M, CF3, CF3M ect

Connection:Flanges

Description
Technical
Standard
Q&A

DESCRIPTION

The GMK DIN ball valve can work with media that have temperatures ranging from -20 degrees Celsius to 180 degrees Celsius and pressures of the PN16 to PN40 type. A home automation starter kit is an available add-on for this product. We have stock available of this item, and it can be sent out right away in any measurement between DN 15 and DN 200. On request, we may provide you with improved measurements, further production tweaks, and unusual materials.

Benefits

The ball can Float and Move in a Straight Line.
“Split body” structure designed in compliance with ISO 17292 construction that makes it multi-function.
An air leak test was carried out byDIN 3230 part 3, so no leakage can be expected.
The top flange results in long durability.
The three types of metals that are used in construction the most often are cast iron, carbon steel, and stainless steel.
Made with special alloys which makes it corrosion free.

Feature:

Two pieces or three pieces design
Floating ball or Trunnion mounted ball, Anti-blow out stem
Fire-safe design and Anti-Static device.
ISO 5211 mounting design upon request
NACE MR-01-75

DIN Ball Valve

TECHNICAL SPECS

Size DN15-DN600

Pressure PN16 PN25 PN40 PN64

Material A105, WCB, CF8, CF8M, CF3, CF3M ect

Connection Flanges

Operate Hand Lever, Gearbox, Penumatic Actuator, Electric Actuator, Hydraulic Actuator

Supply ability 10000 piece/pieces per month

Port Wenzhou/shanghai

Payment terms L/C, D/A, D/P, T/T

Standard

Design and Manufacture: DIN3352
Face to face(end to end): DIN3202 F4 For DN15-100, DIN3202 F5 for DN150-600
End Connection: DIN2543
Test and inspection: DIN3230
