DESCRIPTION

Product Overview

The Cryogenic Ball Valve is designed to control and isolate fluid flow in low temperature pipeline systems. The valve uses a rotating ball with a precision-machined opening to achieve quick shut-off.

When the actuator rotates the ball by 90 degrees, the valve quickly switches between open and closed positions. Therefore, it provides fast operation and reliable sealing performance.

The large flow passage inside the ball creates low pressure loss and reduces turbulence during operation. Moreover, this design improves flow efficiency and helps reduce energy consumption.

The valve is available with two-piece construction, floating ball design, or trunnion mounted ball structure. As a result, customers can select suitable configurations according to different working conditions.

TECHNICAL SPECS

Supply ability 10000 piece/pieces per month

Port Wenzhou/shanghai

Payment terms L/C, D/A, D/P, T/T

Delivery time 7-10 Working day

Design Features and Construction

GMK designs cryogenic ball valves with advanced sealing structures for demanding low temperature applications. Therefore, the valve provides reliable operation in LNG, energy, and industrial systems.

The extended bonnet and stem design increases the distance between the operating components and the cold medium. This feature helps protect packing and sealing components from freezing damage.

Moreover, the valve includes a fire-safe design and anti-static device to improve operational safety. The anti-blowout stem structure also enhances reliability under high pressure conditions.

The valve can be manufactured with floating ball or trunnion mounted ball structures. In addition, different materials and pressure classes are available for various industrial requirements.

Advantages of Cryogenic Ball Valve

The Cryogenic Ball Valve Manufacturer GMK provides valves with excellent flow capacity, reliable sealing, and easy operation. These advantages make the valve suitable for critical cryogenic applications.

First, the full bore design allows smooth fluid flow with minimal pressure drop. Therefore, the valve helps improve system efficiency and reduce operating losses.

Moreover, the quarter-turn operation allows quick opening and closing. This simple operation reduces maintenance requirements and improves overall system reliability.

The durable sealing structure provides long service life under extreme temperature conditions. Furthermore, the compact design makes installation and replacement easier compared with more complex valve types.

In addition, cryogenic ball valves can handle high pressure applications with stable performance. This flexibility allows them to serve different industries and working environments.

Applications of Cryogenic Ball Valve

The Cryogenic Ball Valve is widely used in industries requiring safe control of low temperature fluids. It provides reliable performance for storage, transportation, and processing systems.

Common applications include LNG facilities, natural gas projects, chemical plants, energy systems, oxygen and nitrogen processing, and industrial gas applications.

Moreover, the valve is suitable for pipelines requiring bubble-tight shut-off and low emission performance. Therefore, it provides a dependable solution for modern cryogenic fluid systems.

Technical Specifications and Standards

As a professional Cryogenic Ball Valve Manufacturer, GMK manufactures valves according to international design and testing standards.

The valve design and manufacturing comply with API6D, API608, BS5351, ASME B16.34, and MSS-SP-72 requirements. These standards ensure reliable quality and safe operation.

The pressure-temperature rating follows ASME B16.34 standards. Furthermore, face-to-face dimensions comply with ANSI B16.10 and API6D requirements.

The valve supports flange connections according to ASME B16.5 and ASME B16.47 standards. Butt weld end connections are available according to ASME B16.25 requirements.

All valves are tested and inspected according to API598, API6D, and BS5146 standards before shipment. Fire-safe designs comply with API607 and API6FA requirements.

Standard

Why Choose GMK Valve

GMK is a trusted Cryogenic Ball Valve Manufacturer specializing in industrial valve design and production. We provide customized solutions for customers requiring safe operation and reliable performance.

With professional manufacturing experience, GMK supports different valve designs, materials, pressure classes, and connection types. Therefore, customers can receive suitable cryogenic valve solutions for various projects.

Moreover, our strict quality control system ensures every valve meets international standards before delivery. This commitment helps customers improve safety, reduce maintenance costs, and extend equipment service life.

Q&A

Can we order goods from you directly?

Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.

Can I get a discount?

This depends on the specific situation, you can call directly to consult.
