Forged Steel Pressure Seal Globe Valve

GMK Forged Steel Pressure Seal Globe Valve has disc guides on the top and bottom of the valve. You can operate the stem without the need to counteract any side force from the flow of high-pressure fluid. Because the stem doesn’t turn, there is less wear and tear on the packing and the other components. Because of this, even at high pressures, the GMK valve closes smoothly and securely.

Size:1/2″-2″

Pressure:900LB-2500LB

Material:A105,LF2,F11,F22,F304,F304L,F316, F316L F904L Allay20 ect

Connection:NPT thread,Socket weld,Flange

Description
Technical
Standard
Q&A

DESCRIPTION

GMK uses the tried-and-true ANSI B16.10 pressure seal design.

The body is made of materials like A105,LF2,F11,F22,F304,F304L,F316, F316L F904L Allay20, high-quality forgings and castings that provide exceptional strength. The disc, the seat, and the body all last longer because of the body’s guidance, which also prevents side push. Its handwheel provides a secure shutdown. Our Forged Steel Pressure Seal Globe Valve is a complete package, the stem seal provides a reliable, long-lasting seal with little to no upkeep.

Benefits

Less torque is needed when using a non-rotating stem.
When it comes to erosion and wear resistance, nothing beats the CoCr alloy hardfaced on the body and disc on the seat contact and disc guiding surfaces.
Especially in applications where there are high pressure/temperature transients or frequent cycling, the low-emission service life may be prolonged by the use of live-loaded packing.
There are several possible sizes and pressure ranges. To get technical details, please get in touch with the firm.
As a result of the stem’s reluctance to twist, the packing and the many other components experience far less wear and strain. Because of this, the valve is able to firmly and smoothly shut even when subjected to high pressures.

TECHNICAL SPECS

Size 1/2″-2″

Pressure 900LB-2500LB

Material A105,LF2,F11,F22,F304,F304L,F316, F316L F904L Allay20 ect

Connection NPT thread,Socket weld,Flange

Standard

Design and Manufacture: API602,ANSI B16.34
Face to face(end to end): ANSI B16.10
NPT End Connection: ANSI B1.20.1
SW End Connection: ANSI B16.11
Flange End Connection: ANSI B16.5
Test and inspection: API598

Q&A

Can we order goods from you directly?

Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.

Can I get a discount?

This depends on the specific situation, you can call directly to consult.
