Forged Steel Cryogenic Globe Valve- GMK- For Extreme temperature

Forged Steel Cryogenic Globe Valve

GMK Forged Steel Cryogenic Globe Valve is ideal to use for locations that experience very low temperatures, in keeping with the connotation of their name. In the oil and gas industries, where these valves are often employed, cryogenic temperature ranges starting at as low as -150 degrees Celsius (or 238 degrees Fahrenheit) are the standard. Cryogenic Forged Steel valves are made to safely contain these gases and also to perform well while in transit. They are able to perform well at pressure levels as high as 750 psi and temperature settings as low as -196°C (-320°F), respectively. It is designed to be used in conjunction with cryogenic storage systems.

Size:3/8″-2″

Pressure:800LB

Material:LF2,LF3,F304,F304L,F316,F316L F904L Allay20 ect

Connection:NPT thread,Socket weld

Description
Technical
Standard
Q&A

DESCRIPTION

Forged Steel Cryogenic Globe Valve is given this name because of the movable disc that is housed inside them and forged pieces of components. This disc has the shape of a sphere and rotates at an acute angle to the plane that the seat occupies on the body. It does a good job of sealing for an extended amount of time. It has NPT End Connection: ANSI B1.20.1 and SW End Connection: ANSI B16.11. It is perfect for industrial settings.

Benefits

The loss of product owing to conduction heat transfer may be reduced with the aid of the unique design characteristics of this valve.
Safety is the most noticeable advantage. As a result, the temperature of cryogenic gases must be carefully controlled. T
Cryogenic gas is very cold, and standard valves can’t tolerate pressure and temperature. As a result, Forged Steel Cryogenic Globe Valve valves are built to withstand the extreme cold of the coldest gases.
Applicable in a wide range of industries
Reduced cost.

Feature

Size: 3/8″-2″
Pressure:800LB
Material: LF2,LF3,F304,F304L,F316,F316L ect
Connection: NPT thread,Socket weld

forged-steel-cryogenic-globe-valve

TECHNICAL SPECS

Size 3/8″-2″

Pressure 800LB

Material LF2,LF3,F304,F304L,F316,F316L F904L Allay20 ect

Connection NPT thread,Socket weld

Supply Ability 10000 Piece/Pieces per Month

Port Wenzhou/shanghai

Payment Terms L/C,D/A,D/P,T/T

Standard

Design and Manufacture:API602,ANSIB16.34
Face to face(end to end): Manufacture standard
NPT End Connection:ANSI B1.20.1
SW End Connection:ANSI B16.11
Test and inspection: API598

Q&A

Can we order goods from you directly?

Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.

Can I get a discount?

This depends on the specific situation, you can call directly to consult.
