DESCRIPTION

Working Principle of Non Slam Check Valve

The non slam check valve uses an internal spring mechanism to control the opening and closing process. When the upstream fluid pressure becomes strong enough, the disc moves away from the seat and allows flow to pass.

When the flow rate decreases, the spring pushes the disc back toward the sealing position. As a result, the valve closes before reverse flow develops and effectively reduces water hammer impact.

Furthermore, the short stroke design allows fast response during operation. This feature improves system stability and provides reliable protection for industrial pipeline networks.

TECHNICAL SPECS

Size DN50-DN750

Pressure 150LB,300LB,600LB,900LB,1500LB

Material WCB, LCB,LCC, WC6,WC9, C5,C12,C12A, CF8, CF8M, CF3, CF3M, CN7M,Alloy 20,B148,UB6 ,Hastelloy C etc

Connection Flanges,RTJ Flange

Supply Ability 10000 Piece/Pieces per Month

Port Wenzhou/shanghai

Payment Terms L/C,D/A,D/P,T/T

Features of Industrial Non Slam Check Valve

The industrial non slam check valve features a compact spring-loaded disc structure and reliable sealing design. Therefore, it can be installed in different pipeline positions according to system requirements.

Moreover, the metal-to-metal sealing structure provides excellent durability under demanding working conditions. The valve offers stable performance with low maintenance requirements.

In addition, the conical seat design helps guide the disc accurately and reduces vibration during operation. This structure improves sealing performance and extends the service life of the valve.

Benefits of Spring Loaded Check Valve

The spring loaded check valve provides fast closing performance to minimize water hammer and pressure shock. Therefore, it is an ideal choice for systems that require smooth and silent operation.

Moreover, the valve creates low resistance to fluid flow when fully opened. This design helps improve energy efficiency and maintain stable pipeline performance.

Furthermore, the spring-loaded structure allows flexible installation in horizontal or vertical pipeline systems. As a result, it provides greater convenience for industrial applications.

Applications of Silent Check Valve

The silent check valve is widely used in water supply systems, chemical processing plants, steam condensate systems, and power generation facilities.

Moreover, it is suitable for applications where noise reduction and backflow prevention are important requirements. The reliable closing action helps protect pumps and pipeline equipment.

With advanced manufacturing technology and strict quality control, GMK VALVE delivers dependable check valve solutions for global industrial customers.

Technical Specifications

Product Name: Non Slam Check Valve

Size Range: DN50-DN750

Pressure Rating: 150LB, 300LB, 600LB, 900LB, 1500LB

Material Options: Cast Iron, WCB and Other Materials

Connection Type: Flange, RTJ Flange

Design and Manufacture: BS1868, ANSI B16.34

Pressure Temperature Rating: ASME B16.34

Face to Face: Manufacturing Standard

End Connection: ASME B16.5, ASME B16.47, ASME B16.25

Testing and Inspection: API598, API6D

non-slam-check-valve

Standard

Quality Manufacturing Standards

GMK VALVE manufactures non slam check valves according to international industrial standards. As an experienced Non Slam Check Valve Manufacturer, we focus on reliable design, precise production, and consistent quality control.

Moreover, every valve undergoes strict inspection procedures to ensure proper sealing performance and operational reliability. These quality processes help meet the requirements of worldwide industrial customers.

Therefore, GMK VALVE provides durable non slam check valve solutions for demanding pipeline applications.

Q&A

Can we order goods from you directly?

Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.

Can I get a discount?

This depends on the specific situation, you can call directly to consult.
