13 Things You Should Know About Swing Check Valves

2023-04-30 By ren


Are you in the market for a new check valve? If so, have you considered a swing check valve? Swing check valves are a popular choice in many industries because of their simple design and effectiveness. They work by swinging open to allow fluid or gas through and then closing when the flow stops, preventing backflow. But there’s more to know about swing check valves than just that! In this blog post, we’ll cover everything you need to know about swing check valves – from how they work to installation tips and maintenance advice. So let’s dive into the world of swing check valves!

What is a Swing Check Valve?

A swing check valve is a type of check valve that uses a swinging disc to control the flow of fluid or gas through it. The disc swings open when fluid or gas is flowing in one direction and then swings closed when the flow stops, preventing backflow.

The design of a swing check valve makes it ideal for applications where reliable backflow prevention is necessary, such as in wastewater treatment plants, oil refineries, and chemical processing facilities.

Swing check valves come in various sizes and materials, including stainless steel, brass, bronze, and PVC. They can also be installed horizontally or vertically depending on your needs.

One factor to consider when choosing a swing check valve is its cracking pressure – the minimum pressure required for the disc to begin opening. Some valves have adjustable cracking pressures while others do not.

Swing check valves are an excellent choice for many industries due to their simple yet effective design that ensures reliable performance and minimal maintenance requirements.

How Does a Swing Check Valve Work?

A swing check valve is a type of valve that allows fluid to flow in only one direction. It works by using a swinging disc to block the flow of fluid when it tries to reverse direction.

When fluid flows through the valve in the desired direction, the pressure forces the disc open, allowing for unobstructed flow. As soon as the flow stops or reverses, however, gravity causes the disc to swing back into place and seal off any backflow.

The hinge mechanism on which this disc swings is what gives this type of valve its name – “swing” check valve. The hinge typically sits at or near the centerline of the disk and can be either internal or external depending on design.

Swing check valves are commonly used in applications where preventing backflow is important – such as wastewater treatment plants, pumping stations, and industrial piping systems. They are also frequently employed in HVAC systems where they help regulate airflows within buildings.

Swing check valves offer an effective solution for managing single-directional fluid flows across a wide range of applications with low maintenance requirements and minimal investment costs.

The Different Types of Swing Check Valves

Swing check valves come in different types, each with unique features and applications. The most common types of swing check valves are the horizontal and vertical models.

Horizontal swing check valves work by swinging open to allow fluid flow when pressure is applied from one direction. They then close to prevent backflow when there is no pressure or a decrease in pressure. These valves are ideal for use in pipelines with horizontal or near-horizontal orientation.

Vertical swing check valves operate similarly but are designed for installation in pipelines that have a vertical orientation or where space limitations require the valve to be installed vertically.

Another type of swing check valve is the wafer-style valve which can be used in tight spaces due to its compact design that eliminates flanges necessary on other types of valves. Wafer-style swing check valves also offer low-pressure drop characteristics, making them ideal for systems that demand high efficiency.

Dual disc swing-check valves utilize two half-discs instead of one full disc which provides improved sealing capabilities while reducing wear on the seat ring compared to a standard single-disc model.

Understanding these different types will help you choose the right type of swig-check valve suited for your specific application needs.

Pros and Cons of Swing Check Valves

Swing check valves are popularly used in various industries due to their functionality and efficiency. However, as with any type of valve, there are pros and cons that come with using swing check valves.

One advantage of swing check valves is that they can handle high-pressure applications. They allow for a full flow area, which reduces the pressure drop and minimizes turbulence. Swing check valves also have low head loss compared to other types of valves.

Another benefit of swing check valves is that they require little maintenance since they don’t have many moving parts. This makes them an ideal choice for environments where regular maintenance may not be possible or feasible.

However, one downside of swing check valves is that they can be noisy when opening and closing due to the hinged disc design. Additionally, if debris gets stuck between the hinge mechanism, it can cause malfunction or damage to the valve.

Swing check valves also have limited usage in certain applications since they cannot be installed in vertical pipelines without additional support mechanisms.

While there are some disadvantages associated with using swing check valves, their numerous benefits make them a reliable option for a variety of industrial applications.

How to Install a Swing Check Valve

Installing a swing check valve is not as difficult as it may seem, but it does require some knowledge and tools. Before beginning the installation process, make sure you have all the necessary equipment such as a pipe cutter or saw, wrenches, Teflon tape, and of course the swing check valve itself.

Firstly, shut off the water supply to prevent any accidents from occurring during the installation process. Then using a pipe cutter or saw cut into your existing pipeline at the desired location where you want to install your new swing check valve.

After cutting out a section of pipe that fits your new swing check valve’s dimensions perfectly, clean both ends of this newly created gap with sandpaper or emery cloth for optimal connection performance.

Next up is inserting your new swing check valve in between these two cleaned sections of piping ensuring that everything lines up correctly. Tighten all nuts and bolts securely using appropriate sized wrenches before turning on water again to test whether there are any leaks present.

Lastly wrap Teflon tape around each threaded end before fitting them back together again for extra sealing power against leaks which can cause damage over time if left unchecked.

How to Maintain a Swing Check Valve

Proper maintenance of a swing check valve is crucial to ensure its optimal performance and longevity. Here are some tips on how to maintain your swing check valve:

Firstly, it’s important to regularly inspect the valve for any signs of wear or damage. Check the sealing surface, hinge pin, disc, and body for signs of corrosion or erosion.

Secondly, make sure that the valve is properly installed and aligned with the pipeline. Misalignment can cause excessive wear and tear on the valve components.

Thirdly, keep the surrounding area clean and free from debris that could clog or damage the valve. Regular cleaning will help prevent buildup that can affect proper functioning.

Fourthly, lubricate all moving parts as recommended by the manufacturer. Adequate lubrication will reduce friction between components and minimize wear.

Schedule regular maintenance checks with a qualified technician who can perform more comprehensive inspections and repairs if necessary. This will ensure that your swing check valve continues to function optimally for years to come.

Tips for Troubleshooting a Swing Check Valve

Swing check valves are an important component in any piping system. However, like any mechanical device, they can experience problems that require troubleshooting. Here are some tips to help you troubleshoot swing check valves.

Firstly, if the valve is not closing properly and allowing backflow or leakage, it could be due to debris buildup around the hinge or disc. In this case, disassemble the valve and clean it thoroughly before reassembling.

Secondly, if there is excessive noise coming from the valve during operation, it could indicate a damaged hinge or disc. Inspect these components for damage and replace them if necessary.

Thirdly, if the valve is not opening fully or at all when required, it could be due to a blockage in the system upstream of the valve. Check for obstructions in pipes or filters and clear them as needed.

Fourthly, leaks around the valve body may occur due to loose connections or faulty gaskets. Tighten connections and replace gaskets as needed to prevent leaks.

Regular maintenance such as lubrication of moving parts can help prevent issues with swing check valves before they even occur. By following these tips for troubleshooting swing check valves you can ensure proper functioning of your piping systems without interruptions caused by malfunctioning equipment.


Swing check valves are an essential component of any piping system as they help prevent backflow and protect equipment from damage. With their simple design and easy installation, these valves offer a cost-effective solution for preventing reverse flow.

When choosing a swing check valve, it’s important to consider factors such as the type of fluid being transported, pressure levels, and temperature. It’s also crucial to select the right size and material for optimal performance.

Regular maintenance is necessary to ensure that your swing check valve operates effectively over its lifespan. Follow manufacturer guidelines on cleaning procedures and inspecting parts regularly.

If you encounter any issues with your swing check valve, don’t hesitate to troubleshoot or seek professional assistance when needed. The proper functioning of your system depends on the integrity of each component.

We hope this article has provided valuable insights into what you should know about swing check valves so that you can make informed decisions when selecting, installing, maintaining or troubleshooting them in your piping systems!
