Hastelloy Plug Valve

The GMK Hastelloy plug valves have exceptional anti-corrosion properties in environments with both high oxidative erosion and reductive acidic environment. GMK Hastelloy plug valve is utilized extensively within the chemical processing field. Plug valves are an outstanding product for a broad range of commercial and light industry sectors. Some of these applications include directional access controls, the ability to handle gas or liquid fuel sources, the regulation of liquids with dissolved particles, such as cement slurry, and the management of low-pressure, low-temperature offerings. Plug valves are also an excellent choice for many other applications. GMK Plug valves are used in a wide variety of industries and system configurations because of their smooth design, continuous service possibilities, leak-tight service, minimum resistance to flow, and multi-port layout choice availability.

  • Size:DN15-300mm,NPS1/2″-14″
  • Material:Hastelloy B(N-12MV,N-7M),Hastelloy C(CW-12MW),Hastelloy C276(CW-6MC),Hastelloy C4,Hastelloy G30
  • Pressure:PN1.0-PN1.6
  • Temperature:-29℃-+330℃

CE Certification

ISO Standards

Warranty Included


We are one of the most in-demand Plug Valve Makers because our GMK Hastelloy plug valves are created and constructed to give excellent results under efficient working procedures.  The item, in general, has fewer requirements for service and results in lower costs. Our Hastelloy plug valves find widespread use in a variety of different industries, including the petroleum and gas industry, pipelines, power stations, cement factories, chemical plants, specialty chemicals, and numerous others.


  • Plug valves provide several benefits in addition to their small size and reduced profile, including the following:
  • Stream Regulation provides a secure shut-off, a rapid reopening, and a limited pressure decrease.
  • Because the real plug and the body seating surface are not accessible to the line fluid, there is a lower risk of rust or erosion occurring. This contributes to the longevity of the product.
  • It has Superior resistance to cracking caused by stress and corrosion.


The valve seat may be easily replaced in the event of damage. It’s anti-static and helps avoid fires.


The steam from the valve is utilized to keep things from going awry, and the valve also includes a safety lock feature to keep anything from escaping. Used in acetic aid, chemical engineering, aircraft, and any other corrosive media imaginable.


Size DN15-300mm,NPS1/2″-14″
Material Hastelloy B(N-12MV,N-7M),Hastelloy C(CW-12MW),Hastelloy C276(CW-6MC),Hastelloy C4,Hastelloy G30
Pressure PN1.0-PN1.6
Temperature -29℃-+330℃
Supply Ability 10000 Piece/Pieces per Month
Port Wenzhou/shanghai
Payment Terms L/C,D/A,D/P,T/T
  • Design Standard: API 599
  • Face To Face: ASME B16.10
  • Flange Ends: ASME B16.5
  • Test And Inspection: API 598
Can we order goods from you directly?
Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.
Can I get a discount?
This depends on the specific situation, you can call directly to consult.
