Three Way Ball Valve- GMK- Three port Valve having three openings

Three Way Ball Valve

GMK three-way ball valve is a valve that has three ports or apertures that are connected to pipe or tubing. The aim of this valve is to allow for the passage of gas or fluid (the medium). It is standard practice to refer to these apertures as either one inlet and two outlets or one outlet and two inlets, depending on the direction of flow through the valve. However, depending on the direction of flow through the valve, it is also possible to refer to these openings as two outlets. The ability of GMK three-way ball valves to regulate flow in three distinct directions at the same time has led to their widespread adoption as a result of their low cost and intuitive operation.

Size:1/2″-24″

Rating:150LB,300LB

Material:WCB, LCB,LCC, WC6,WC9, C5,C12,C12A, CF8, CF8M, CF3, CF3M, CN7M,Alloy 20,B148,UB6 904l,Hastelloy C etc

Connection:Flanges

Operate:Hand lever, Gearbox, Penumatic Actuator

Description
Technical
Standard
Q&A

DESCRIPTION

GMK three-way ball valve is highly functional. Three-way ball valves have three pipe connections. When it comes to handling circumstances that need precise management of fluid flow, GMK three-way valves are preferable. Because of its three openings, it is suitable for usage in a diverse range of different process settings. For example, combining filtered water and juice concentrate from two separate containers may be accomplished with the help of a three-way ball valve in its ball valve form. The design of a three-way valve makes it possible to transfer gasoline from one tank to another while retaining the capability to entirely shut off the fuel supply.

Benefits

Prevent or put a halt to the flow of
It is possible for you to switch between two different flow sources.
Combine the results obtained from two different sources
The shifting pattern of vehicular movement between two distinct locales.
Alter the path of a stream such that it flows in a direction different from its intended destination.
Create two independent outlets from the output of a single input.

Feature

One Piece or two pieces design
L type(3 way/2ports) and T type(3 way/3 ports)
Floating ball
Full Port
Low torque value
Anti-blow out stem
Fire safe design and anti-static device
ISO 5211 mounting design upon request
NACE MR-01-75

TECHNICAL SPECS

Size 1/2″-24″

Rating 150LB,300LB

Material WCB, LCB,LCC, WC6,WC9, C5,C12,C12A, CF8, CF8M, CF3, CF3M, CN7M,Alloy 20,B148,UB6 904l,Hastelloy C etc

Connection Flanges

Operate Hand lever, Gearbox, Penumatic Actuator

Supply Ability 10000 Piece/Pieces per Month

Port Wenzhou/shanghai

Payment Terms L/C,D/A,D/P,T/T

Standard

Design and Manufacture:API6D, ASME B16.34
Pressure-temperature rating: ASME B16.34
Face to face(end to end):Manufacture standard
End Connection: ASME B16.5
Test and inspection:API598,API6D
Fire safe:API607,API6FA

Q&A

Can we order goods from you directly?

Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.

Can I get a discount?

This depends on the specific situation, you can call directly to consult.
