DIN Bellows Seal Globe Valve

Bellows globe valve, often referred to as DIN Bellows Seal Globe Valve has the presence of bellows inside the valve. The design of the double seal also ensures that there will be no leaks, even in the event that the bellows fail to properly pack the stem. To maintain constant working performance and reduce stem vibration, the bellows are soldered to the valve stem. GMK provides top quality bellow valve.

  • Supply Ability:10000 Piece/Pieces per Month
  • Port:Wenzhou/shanghai
  • Payment Terms:L/C,D/A,D/P,T/T

CE Certification

ISO Standards

Warranty Included


GKM DIN Bellows Seal Globe Valve is leakage free. An automated seam welding process is used to construct a metal barrier to ensure no leakage in GMK DIN Bellows Seal Globe Valve. The metal barrier is placed between the fluid medium and the surrounding environment. It incorporates a bellows structure on the inside, and the lower end of the stainless-steel bellows is welded to the valve stem in order to prevent the process fluid from eroding the valve stem. It is ideally suited for use in pipelines transporting steam as well as other media such as flammable, explosive, heat transfer oil, high-purity, and toxic substances.


  • It is a product with a reasonable design, dependable sealing function, and a lovely aesthetic appearance.
  • Sealing surfaces surfaced with Co-based cemented carbide, which provides high wear and corrosion resistance, low friction, and long service life.
  • The valve stem has been quenched, tempered, and nitrided on the surface, giving it excellent resistance to corrosion and friction.
  • It’s easier to understand the valve lift position indicator.
  • To accommodate a wide range of technical requirements, the kind of material, the number of flanges, and the size of the butt welds are all fairly chosen based on real working circumstances or user requirements.


Supply Ability 10000 Piece/Pieces per Month
Port Wenzhou/shanghai
Payment Terms L/C,D/A,D/P,T/T
  • Design and Manufacture: DIN 3356
  • Face to Face: DIN 3202
  • Flange end: DIN 2543-2545
  • Test & Inspection: DIN 3230
Can we order goods from you directly?
Yes, we look forward to receiving your order. However, please note our minimum purchase quantity. If you require smaller quantities we will be happy to arrange an individual delivery. We would be delighted to assist you.
Can I get a discount?
This depends on the specific situation, you can call directly to consult.
