ANSI Standard Bellows Seal Globe Valve For High Pressure

An ANSI Standard Bellows Seal Globe Valve for High Pressure is available at GMK. An element of the bellow seal is the connection made using automated roll welding between the cover and the stem. The metal below may prevent any leaking from occurring in the stem section. The disc has a reliable seal and a longer service life as a result of the con and streamlined form design. GMK standard bellow valve includes ANSI standard and extended high-pressure sealing bonnet.

  • Supply Ability:10000 Piece/Pieces per Month
  • Port:Wenzhou/shanghai
  • Payment Terms:L/C,D/A,D/P,T/T

CE Certification

ISO Standards

Warranty Included


It has a design that has a double seal (bellows and packaging). Bellow and packing may offer a good seal in addition to providing protection against leaking. Its structure has a grease nipple. It has the ability to directly lubricate the stem as well as the nut and the sleeve. It has a hand wheel with an ergonomic design. The ANSI Standard Bellows Seal Globe Valve for High Pressure has a longer life expectancy and simpler operating requirements.


  • When there are fewer limits on fluid resistance or pressure loss, these materials are suitable for use in pipelines.
  • It is appropriate for use with flow media that have high temperatures and high pressures in equipment and pipes, as well as steam mediums in pipelines that have DNS that are smaller than 200 mm.
  • For applications that include both a high temperature and a high pressure, such as steam, valve installations are performed such that the pressure is above the disc.
  • The use of these valves may be beneficial for applications on a smaller scale, such as instruments, pressure gauges, sampling, and other similar applications.
  • For the safest possible handling of very hazardous material, bellows-sealed valves are your best option.



Supply Ability 10000 Piece/Pieces per Month
Port Wenzhou/shanghai
Payment Terms L/C,D/A,D/P,T/T
  • Design and Manufacture: API 16.34
  • Face to Face: ANSI B16.10
  • Flange end: ANSI B 16.5
  • Test and Inspection: API 598
